Schneider Contactor Control Relay Switching 5 Pole 10A 24V 3NO/2NC DIN Rail/Plate Mount
Schneider Contactor Control Relay Switching 5 Pole 10A 24V 3NO/2NC DIN Rail/Plate Mount
In stock
SKU
TEECAD32B7
Contactor Control Relay Switching, AC15 Rating: 240 Volt AC at 10 Amp, 24 Volt AC, 3NO/2NC, 5 Pole, Operating Time: 12-22, 4-12 ms NO, 4-19, 6-17 ms NC, Screw Clamp, DIN Rail/Base/Plate Mount, IP2x, -40 to 60 deg C, 77 mm Height, 45 mm Width, 84 mm Depth
| Brand | Schneider |
|---|---|
| Range Name | TeSys Model D |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121500 |
| UOM | EA |
| Vendor Product | CAD32B7 |
| AC15 Rating | 10 Amp 240 Volt |
| Contact Configuration | 3 Normally Opened & 2 Normally Closed |
| Height | 77 mm |
| Depth | 84 mm |
| IP Rating | IP2x |
| Mounting Method | DIN Rail/Base/Plate |
| Number Of Poles | 5 Pole |
| Operating Coil Voltage | 24 Volt AC |
| Operating Time | 12-22 4-12 ms NO/4-19 6-17 ms NC |
| Product Type | Contactors Switching |
| Temperature | -40 to 60 deg C |
| Terminal Connection | Screw Clamp |
| Width | 45 mm |
Description
Contactor Control Relay Switching, AC15 Rating: 240 Volt AC at 10 Amp, 24 Volt AC, 3NO/2NC, 5 Pole, Operating Time: 12-22, 4-12 ms NO, 4-19, 6-17 ms NC, Screw Clamp, DIN Rail/Base/Plate Mount, IP2x, -40 to 60 deg C, 77 mm Height, 45 mm Width, 84 mm Depth
