Sprecher+Schuh Operator Contact Block With Screw Terminals 1N.O 110-120/240/125VAC/DC DIN Rail/Base Mount

Sprecher+Schuh Operator Contact Block With Screw Terminals 1N.O 110-120/240/125VAC/DC DIN Rail/Base Mount

In stock
SKU
S&SD7-BX10
Add to Compare
main product photo
Operator Contact Block, 690 Volt AC/DC, 10 Amp, 1 Normally Opened Configuration, Screw Terminal, DIN Rail/Base Mounting, IP65/66, Glass-Filled Nylon/PA6/PA66 Housing, -25 to 70 deg C, 22.5 mm
More Information
More Information
Features
  • D7 pilot devices offer maximum flexibility and a wide choice for all 22.5 mm operator applications with all type (e-stops, selector switches, pushbuttons, pilot lights and more), colour and contact configurations
  • Aesthetically appealing and modularly designed to make assembly and interchangeability easy
  • Operators exhibit low profile and stylish appearance while maintaining the rugged performance necessary for demanding environments
  • D7P is a plastic operator with a captive black plastic front bezel
  • Constructed of high grade thermoplastics, the D7P operators provide strong chemical resistance making them suitable for use in different environments and strong chemical resistance
  • D7M has a die-cast zinc housing and mounting ring for rugged durability
  • Finished with corrosion resistant chrome plating, the D7M also features a captive shiny metal bezel for a polished appearance
Brand Sprecher+Schuh
Range Name D7
Standard Pack Size 1
UNSPSC Class 39122200
UOM EA
Vendor Product D7BX10
Contact Configuration 1 Normally Opened
Current 10 Amp
Housing Material Glass-Filled Nylon/PA6/PA66
IP Rating IP65/66
Mounting Method DIN Rail/Base
Product Type Operator Contact Blocks
Size 22.5 mm
Temperature -25 to 70 deg C
Terminal Connection Screw
Voltage 690 Volt AC/DC

Description

Operator Contact Block, 690 Volt AC/DC, 10 Amp, 1 Normally Opened Configuration, Screw Terminal, DIN Rail/Base Mounting, IP65/66, Glass-Filled Nylon/PA6/PA66 Housing, -25 to 70 deg C, 22.5 mm
