Flex High Temp 1C 0.5mm XLPO Black +125C 450/750V

Radox R125 High Temperature Flexible Wire Single Insulated 1 Core 0.5mm 450/750V XLPO Black

In stock
SKU
RADR125/0.5/BLK
Add to Compare
main product photo
Flexible Wire, Single Insulated, High Temperature, 1 Core, 0.5 mm, Stranded Tinned Copper, 450/750 Volt, 19/0.18 mm Strands, 1.7 mm Overall Diameter, LSZH XLPO Insulation, Unsheathed, Black Insulation, -40 to 125 deg C
More Information
More Information
Features
  • High current carrying capacities
  • Electron beam crosslinked
  • Short circuit temperatures of up to 280 deg C with no change to material properties
  • Easy processability (removal of insulation etc.)
  • Excellent resistance against all conventional impregnating varnishes and potting resins
  • Flexible
  • Good abrasion resistance and mechanical properties
  • Good resistance to ozone, UV and sunlight radiation
  • Thermal Class B
Brand Radox
Range Name R125
Standard Pack Size 100
UNSPSC Class 26121600
UOM MTR
Vendor Product R125/0.5/BLK
Conductor Type Stranded Tinned Copper
Insulation Material LSZH XLPO
Insulation Colour Black
Overall Diameter 1.7 mm
Sheath Material Unsheathed
Stranding 19/0.18 mm
Temperature -40 to 125 deg C
Voltage 450-750 Volt
Conductor Size 0.5 mm
Number of Cores 1 Core
Product Type Flexible Cable High Temperature

Description

Flexible Wire, Single Insulated, High Temperature, 1 Core, 0.5 mm, Stranded Tinned Copper, 450/750 Volt, 19/0.18 mm Strands, 1.7 mm Overall Diameter, LSZH XLPO Insulation, Unsheathed, Black Insulation, -40 to 125 deg C

Infosheets
